Description
Key Product Features:
- Ideal for comfortable air flow in wide rooms thanks to Coanda effect: up to 100° discharge angle
- Even rooms with ceilings up to 3.8m can be heated up or cooled down very easily without capacity loss
- Can easily be installed in both new and refurbishment projects
- Combining with R-32 Bluevolution technology, reduces environmental impact with 68% compared to R-410A, leads directly to lower energy consumption thanks to its high energy efficiency and has up to lower 16% refrigerant charge
- Can easily be mounted in corners and narrow spaces, as it only needs 30mm lateral service space
- Unified indoor unit range for R-32
- Reduced energy consumption thanks to specially developed DC fan motor
- 5 different fan speeds available for maximum comfort
- Stylish unit blends easily with any interior. The flaps close entirely when the unit is not operating and there are no air intake grilles visible
Technical Data:
| FHA50A+RXM50M9 | |||||
| Casing | Colour | White | |||
| Material | Resin, sheet metal | ||||
| Dimensions | Unit | Height | mm | 235 | |
| Width | mm | 960 | |||
| Depth | mm | 690 | |||
| Weight | Unit | kg | 25.0 | ||
| Fan | Air flow rate | Cooling | High | m³/min | 15.0 |
| Low | m³/min | 10.0 | |||
| Heating | High | m³/min | 15.0 | ||
| Low | m³/min | 10.0 | |||
| Sound power level | Cooling | dBA | 54 | ||
| Sound pressure level | Cooling | High | dBA | 37 | |
| Low | dBA | 32 | |||
| Heating | High | dBA | 37 | ||
| Nom. | dBA | 35 | |||
| Piping connections | Liquid | OD | mm | 6,4 | |
| Gas | OD | mm | 12.7 | ||
| Drain | VP20 | ||||
| Standard Accessories | Item | 2 | |||
| Item | 7 | ||||
| Item | 1 | ||||
| Item | 1 | ||||
| Item | 8 | ||||
| Item | 1 | ||||
| Item | 1 | ||||
| Item | 1 | ||||
| Item | 2 | ||||
| Item | 2 | ||||
| Power supply | Phase | 1~ | |||
| Frequency | Hz | 50 | |||
| Voltage | V | 220-240 | |||
| Notes_Description | See separate drawing for electrical data | ||||
| Cooling capacity | Total capacity | Nom. | kW |
