Description
Product Key Feature’s:
• Touch Screen easy use controller with weekly programming
• High Head Drain Pump
• Auto Changeover of modes
• Low Standby Power
• Auto Restart after power outage
• Easy-to-Clean Air Filter
• Two Thermistor Control (one in the unit and on in the controller)
• Optimal Air Distribution
• Auto Operation
• Quiet Operation
• Healthy De-humidification
• Hot Start
• 24-Hour ON/OFF Setting Timer
• Optimal air distribution with 4-way directional Air flow system.
• 4-way Auto Swing
Specification:
| Type | Inverter heat pump | |||
| Model name | AOYG07KETA | |||
| Power supply | 230 V ~ 50 Hz | |||
| Available voltage range | 198—264 V | |||
| Starting current | A | 3.0 | ||
| Fan | Airflow rate | Cooling | m3/h | 1,650 |
| Heating | 1,450 | |||
| Type × Q’ty | Propeller fan × 1 | |||
| Motor output | W | 23 | ||
| Sound pressure level *1 | Cooling | dB (A) | 46 | |
| Heating | 46 | |||
| Sound power level | Cooling | dB (A) | 61 | |
| Heating | 61 | |||
| Heat exchanger type | Dimensions (H × W × D) | mm | 504 × 650 × 18.2 | |
| Fin pitch | 1.3 | |||
| Rows × Stages | 1 × 24 | |||
| Pipe type | Copper | |||
| Fin type | Type (Material) | Corrugate (Aluminum) | ||
| Surface treatment | PC Fin | |||
| Compressor | Type × Q’ty | DC rotary × 1 | ||
| Motor output | W | 550 | ||
| Refrigerant | Type (Global warming potential) | R32 (675) | ||
| Charge | g | 600 | ||
| Refrigerant oil | Type | RB74AF | ||
| Amount | cm3 | 240 | ||
| Enclosure | Material | Steel sheet | ||
| Color | BeigeApproximate color of Munsell 10YR 7.5/1.0 | |||
| Dimensions (H × W × D) | Net | mm | 541 × 663 × 290 | |
| Gross | 602 × 804 × 375 | |||
| Weight | Net | kg | 23 | |
| Gross | 26 | |||
| Connection pipe | Size | Liquid | mm (in) | Ø 6.35 (Ø 1/4) |
| Gas | Ø 9.52 (Ø 3/8) | |||
| Method | Flare | |||
| Pre-charge length | m | 15 | ||
| Max. length | 20 | |||
| Max. height difference | 15 | |||
| Operation range | Cooling | °C | -10 to 46 | |
| Heating | -15 to 24 | |||
| Drain hose | Material | PP+LLDPE | ||
| Size | mm | Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.) | ||
| NOTES:Specifications are based on the following conditions:Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.Pipe length: 5 m, Height difference: 0 m.Protective function might work when using it outside the operation range.*1: Sound pressure levelMeasured values in manufacturer’s anechoic chamber.Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here. | ||||
| Model name | AUXG07KVLA | ||||
| Power supply | 1Ø 230 V ~50 Hz | ||||
| Available voltage range | 198—264 V | ||||
| Capacity | kW class | 2.0 | |||
| Input power | W | 18 | |||
| Running current | A | 0.15 | |||
| Fan | Airflow rate | Cooling | HIGH | m3/h | 540 |
| MED | 490 | ||||
| LOW | 440 | ||||
| QUIET | 390 | ||||
| Heating | HIGH | 540 | |||
| MED | 490 | ||||
| LOW | 440 | ||||
| QUIET | 390 | ||||
| Type × Q’ty | Turbo fan × 1 | ||||
| Motor output | W | 54 | |||
| Sound pressure level * | Cooling | HIGH | dB (A) | 33 | |
| MED | 31 | ||||
| LOW | 29 | ||||
| QUIET | 27 | ||||
| Heating | HIGH | 34 | |||
| MED | 32 | ||||
| LOW | 29 | ||||
| QUIET | 27 | ||||
| Sound power level | Cooling | dB (A) | 46 | ||
| Heating | 47 | ||||
| Heat exchanger type | Dimensions (H × W × D) | mm | 210 × 1,310 × 13.3210 × 1,250 × 13.3 | ||
| Fin pitch | mm | 1.2 | |||
| Rows × Stages | Main1: 1 × 10Main2: 1 × 10 | ||||
| Pipe type | Copper tube | ||||
| Fin type | Aluminium | ||||
| Dimensions (H × W × D) | Net | mm | 245 × 570 × 570 | ||
| Gross | 265 × 730 × 625 | ||||
| Weight | Net | kg | 15 | ||
| Gross | 19 | ||||
| Connection pipe | Size | Liquid | mm (in) | Ø6.35 (Ø1/4) | |
| Gas | Ø9.52 (Ø3/8) | ||||
| Method | Flare | ||||
| Operation range | Cooling | °C | 18 to 32 | ||
| %RH | 80 or less | ||||
| Heating | °C | 16 to 30 | |||
| Drain hose | Material | PVC | |||
| Size | mm | VP25 (Ø 25 [I.D.], Ø 32 [O.D.]) | |||
| Cassette grille (Grid type: Option) | Model name | UTG-UFYF-W | |||
| Material | Polystyrene | ||||
| Color | WhiteApproximate color of Munsell 9PB 9.1/0.2 | ||||
| Dimensions (H × W × D) | Net | mm | 49 × 620 × 620 | ||
| Gross | 120 × 765 × 755 | ||||
| Weight | Net | kg | 2.3 | ||
| Gross | 4.5 | ||||
| NOTES:The protective function might work when using it outside the operation range.*: Sound pressure level:These are the measured values in the manufacturer’s anechoic chamber.Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here. | |||||
